SINGLE WALL CHIMNEY SYSTEMS

Falken Single single-wall flue systems have been developed to deliver the waste gases of heating units operating with gas and liquid fuel types to the atmosphere. According to the specific information of the heating units, Falken Chimney Systems are also used in solid fuel types by increasing wall thickness and changing the material type.

The chimney system, in general, is a straight module. TE Module consists of elbow, cleaning cover, reduction and flat elements. Single walled chimney systems from Ø100 to Ø1000 diameter in wall thicknesses of 0.4 mm, 0.5 mm, 0.6 mm, 0.8 mm, 1.0 mm, 1.2 mm, 1.5 mm, 2.0 mm acid resistant stainless steel AISI 316L (DIN 1.4404) quality.

Standard production up to 400 ° C, temperature resistant products up to 600ºC has the ability to withstand trouble-free. High precision chimney modules are welded by robot-plasma welding technique. The modules provide excellent sealing and stability with a 50 mm baffle plug and are easy to install.
